SKU:
TT-TGR-XXX
China
pieces and more per hour*
Compatible with
the following screen printing systems:
and many more!
Textalk TGR Series is a digital hybrid printer that extends the capabilities of your screen printing system by adding DTG printing to the workflow. Textalk TGR Series hybrid printer is an efficient and cost-effective solution for digital print mass production on various textiles, such as clothing, home textiles, and promotional items. The TGR Series uses the Ricoh printheads for high-performance printing.
Available on backorder
OR
The Textalk TGR Series is designed to seamlessly integrate both traditional screen printing and digital DTG printing. It is equipped with an intelligent drive system that ensures super-smooth and accurate high-speed movement of the carriage in either direction. With its impressive printing speed, the Textalk TGR Series printer can produce up to 410 A4-sized prints per hour. The printer enables manufacturers to adapt swiftly to changing trends and produce garments in line with current fashion demands.
If you are planning to run a large-scale operation, choosing both reliable automatic screen printing equipment and digital hybrid printer will be crucial. The Textalk TGR Series Hybrid Printer is designed with compatibility in mind. This intelligent drive system offers a super smooth and accurate high-speed movement of the carriage in either direction. Its flexibility allows it to integrate this digital hybrid printer into your current production line seamlessly. That is to say, the learning curve is gentle, and your current screen printing setup enhanced with digital capabilities can be up and running at full capacity in no time.
If you have already owned a screen printing machine, we can install the Textalk TGR Series Hybrid printer onto your existing setup.
Textalk Hybrid TGR Series Printer over
the Oval Screen Printing Machine
Textalk Hybrid TGR Series Printer over
Textalk Oval Screen Printing Machine
Depending on the particular printer model, Textalk TGR have different variables:
|
TGR712
|
TGR715
|
---|---|---|
Amount of printheads:
|
12
|
15
|
Sizes (LxWxH):
|
2705x2113x1865
|
|
Weights:
|
1040kg
|
|
Speed recommended (A4):
|
440pcs
|
|
High Resolution mode (A4):
|
340pcs
|
|
Single step length:
|
160.6mm
|
270.4mm
|
Maximum printing area: X/Y
|
700x600mm
|
650x7000mm
|
Wide color gamut
The exceptional feature of the Textalk TGR Hybrid printer resides in its ability to produce an extensive and dynamic range of colors. This printer is capable of producing a broad and vibrant range of colors, ensuring that your printed materials are vivid and accurate color.
Industrial-grade Starfire printhead
Textalk TGR Series Hybrid Printer is designed with 12 and 15 printheads from Ricoh depending on printer configuration. It is a high-quality printhead that utilizes the latest inkjet technology to deliver exceptional print quality, speed, and consistency.
Durable body for industrial use
The Textalk TGR Series Hybrid Printer is a high-quality, industrial-grade printer designed for high-volume production. Its durable and robust build ensures smooth and consistent printing, making it a reliable choice for businesses looking to streamline their printing process. This machine boasts a sturdy frame made of steel and aluminum, which provides it with the necessary stability to handle heavy workloads over years of operation.
Cost-effective solution
The Textalk TGR printer revolutionizes garment printing for industrial textile production. With its innovative combination of screen printing and DTG (Direct-to-Garment) printing technologies, this product facilitates a cost-effective solution for high-volume production.
Made in China
Textalk TGR Series Hybrid Printer is a high-performance digital DTG printer proudly made in China. It is designed to meet the demands of contemporary textile printing businesses, offering exceptional quality, speed, and versatility. It is a reliable and efficient machine that combines China craftsmanship and innovation to help businesses achieve the highest levels of success in the digital garment printing industry.
“A breakthrough inkjet printhead from Ricoh, the MH5421 is intended for applications requiring high performance printing and decorating.”
The Ricoh MH5421 500MM Printhead is a printing component of remarkable quality and performance. It features a native resolution of 600 dpi, ensuring precision and clarity in printed output. This printhead offers the impressive capability to jet up to 4 colors, rendering it suitable for a wide range of color printing applications. Moreover, it exhibits compatibility with various types of inks, including UV, solvent, water-based, and others. Its variable drop capacity, supporting 4 levels of grey, allows for precise control, enhancing the overall print quality.
Features:
Ink Ejection: The printhead ejects ink droplets with remarkable accuracy to create high-resolution prints.
Color Printing: It supports up to four colors, allowing for versatile and colorful output.
Variable Drop Sizes: The printhead can produce variable drop sizes, contributing to fine detail and shading in printed images.
Support for Different Inks: It can be used with various types of inks, including UV, solvent, water-based, and more, making it adaptable to a wide range of applications.
The Ricoh MH5421 500MM Printheads has a total length of 650mm, which includes the head body, cable, and connectors. A 550mm cable is a versatile option for water-based digital printers, that gives excellent performance by supporting up to two colors and having 1,280 nozzles. Ricoh products are covered by manufacturer warranties, so quality can be assured.
Parameter
|
Ricoh MH5421 500MM
|
---|---|
Number of Nozzles
|
4 x 320 nozzles
|
Print width
|
54.1mm
|
Grayscale printing
|
4 grey-scale per dot
|
Ignition Frequency
|
Binary mode 30K/Gray mode 20k
|
Minimun ink dot
|
Binary mode 7PL
|
Average life span
|
2 – 3 years
|
Resolution
|
600 dpi
|
Dimensions
|
89 x 25 x 69 mm (excluding cables)
|
Operator temperature range
|
Up to 80° C
|
Integral temperature sensor
|
Included
|
Buy Ricoh MH5420 Printhead
|
Textalk enviromentally friendly pigment ink stands out in the world of industrial grade hybrid printing. Designed to deliver deep, rich blacks and outstanding color saturation, it’s engineered to deliver impeccable color quality. The inkset shows excellent color fastness to washing, dry/wet rubbing fastness, and bright colors.
The Textalk pigment ink offers garment and textile printers a whole new level of creativity. Featuring six vibrant ink colors:
Textalk pigment inks are A-01 and OEKO-TEX® approved.
This digital pigment ink is sunlightproof, scratch resistant and durable. It is used for cotton, linen, wool and blended fabrics, direct-injection printing, the fabric feels soft after printing, and conforms to the ecological textile standard (Oeko-Tex standard100). The ink has also passed the A-01 verification, and has various test verification reports from professional testing institutions SGS and Intertek, we can assure that products are compliant with the requirements of different countries around the world.
The Textalk Hybrid Printer leverages the NeoStampa RIP Software to achieve the best possible printing performance. Compatible with many brands of printers on the market, NeoStampa has a user-friendly interface and is straightforward to use, offering advanced technology for image processing. This RIP Software have a powerful color management engine and multiple options for cost control, image editing, calibration and print profiling make neoStampa the best available solution. And benefits from using multiple features:
NeoStampa RIP Software ensures accurate color output for various textile printers and inks, including dye sublimation and DTG units, like Textalk Hybrid printers. Designed specifically to enhance productivity, Neostampa RIP maintains user-friendly interface while increasing productivity to new heights. It can process and print various file formats commonly used in the printing industry, such as PDF, TIFF, JPEG, and more.
Cotton, Linen, polyester, nylon
Maximum print size:
Printhead:
Ricoh MH5421 500MM Printhead
Printing resolution:
3 PASS: 635*800dpi or 635*1200dpi
RIP Software / operating system
Neostampa/Windows
Ink Types & Volume
Textalk Oval Printing Pigment Digital Ink; 4 Colors: CMWK, 6 Colors: CMWKGR
Environmental conditions:
Temperature: 25 – 28°C; Humidity 55 – 65 %
Dimensions and Weight:
2705 x 2113 x 1865cm / 1040kg
Printhead Manternance:
Automatic cleaning, ink scraping, moisturizing, anti-collision
