aeoon Kyo Series DTG Printer
aeoon Kyo Series DTG Printer Offer
available in Vietnam and Asia-Pacific*-
aeoon DTG Printer
with 1 Year OEM Warranty -
Ink Set: DuPont Color G inks:
White + CMYK + Spot colors (optional) -
Maintenance Kit: cleaning fluids and consumable parts
-
aeoon RIP Software v7
-
On-site installationby aeoon-certified technicians
-
5-day Print Training
Get Your Custom Quote
The offer is valid for Vietnam, Thailand, Laos, Cambodia, Malaysia, Singapore, Hong Kong and China.
* Depending on the machine configuration, performance of the operator, on the material and design, and on dark / colored garment. Print size up to: 92 x 98cm.
Order high quality samples printed by aeoon DTG printer FREE OF CHARGE!
The aeoon Kyo Series DTG printer is a high-end and industrial-grade digital direct-to-garment printer. The aeoon Kyo is known for its fast-printing speeds, allowing for rapid production of large quantities of printed textiles in sizes of up to 200 x 98 cm. It can handle both small and large print runs efficiently, and it is easy to integrate into an automated production workflow.
Built with durable construction and reliable components, the aeoon Kyo printer is designed to withstand demanding industrial environments and ensure long-term performance. The aeoon Kyo Series printer can be equipped with up to 12 printheads, which allows the use of additional spot colors to achieve wider color gamut and higher color accuracy.
Highlights
Printheads
Configuration
Kyo PLUS
Inks
RIP
Brochures
Technical Data
Highlights
Touchscreen and User-friendly software
The aeoon Kyo DTG Printer comes equipped with a high-resolution touchscreen display, which allows users to easily control the printing process and make adjustments on-the-fly. The intuitive software that comes with the printer makes it easy for users to upload designs, adjust settings, and print high-quality images on a variety of garments.
Up to 12 Kyocera industrial printheads
aeoon Kyo Series DTG Printer is designed with 4, 8 or 12 printheads Kyocera KJ4B-QA depending on printer configuration. It is a high-quality printhead that utilizes the latest inkjet technology to deliver exceptional print quality, speed, and consistency.
Durable body for industrial use
The aeoon Kyo Printer is a high-quality, industrial-grade printer designed for high-volume production. Its durable and robust build ensures smooth and consistent printing, making it a reliable choice for businesses looking to streamline their printing process. The printer boasts a sturdy frame made of steel and aluminum, which provides it with the necessary stability to handle heavy workloads over years of operation.
High-precision linear axis
With its advanced design and precision engineering, featuring the movements of the carriage with high accuracy, aeoon Kyo printer is capable of producing high-resolution DTG prints with sharp and vibrant colors, making it an ideal choice for printing detailed graphics and photographic images onto a wide range of fabrics.
Two or Three axis with exchangeable pallets
The aeoon Kyo Printer is equipped with 2 or 3 pallets that allow for efficient printing of multiple garments simultaneously. These pallets can be quickly and easily swapped out between prints, allowing for increased productivity and reduced downtime. Additionally, each pallet is designed to accommodate a wide range of garment sizes and styles, whether it be T-shirts, sweatshirts or hoodies. Largest priting size is 200 x 98 cm.
POD Fulfilment: Ready to automate
The Kyo Series is easy to integrate into an automated production workflow. Whether you’re a small business just starting out or a larger company experiencing growth, aeoon printing systems can adapt to meet your needs. Plus, the systems are incredibly easy to integrate. Say goodbye to the headache of manual order fulfillment and hello to streamlined automation.
Automatic cleaning and capping station
The Automatic Cleaning is an important feature in the aeoon Kyo DTG printer. It is designed to keep the printhead of the printer clean and protected when not in use. The capping station works by automatically moving the printhead into position for cleaning and capping and then retracting it when the process is complete. When the printer is not in use, the station keeps the printhead securely capped to prevent any dust or debris from getting onto the surface. This helps maintain the integrity of the printer and ensures it is always ready to produce high-quality prints.
Made in Austria
aeoon Kyo series printer is a high-performance digital DTG printer proudly made in Austria. It is designed to meet the demands of contemporary textile printing businesses, offering exceptional quality, speed, and versatility. It is a reliable and efficient machine that combines Austrian craftsmanship and innovation to help businesses achieve the highest levels of success in the digital garment printing industry.
PLUS Series: integrated heat press
The integrated heat press is an innovative feature for the aeoon Kyo PLUS Series that allows for a streamlined printing process, where the garment is printed and pressed in one machine. The heat press is controlled within the printer software and can be easily adjusted for temperature and pressure. It helps to:
- save on labor costs,
- increase efficiency,
- reduce the risk of misprints or damage to the garment during transportation between machines.
Printheads
Kyocera KJ4B-QA printhead
The KJ4B-QA printhead is designed by Kyocera for high speed printing using water-based inks.
The Kyocera KJ4B-QA is equipped with internal filters that eliminate foreign objects in ink and an internal heater that adjusts the impact of external temperatures. Its unique ink channel design provides a stable ink supply.
|
Kyocera KJ4B-QA Printhead: Technical Specifications
|
|
|---|---|
|
Ink Type
|
Water-based
|
|
Width × Depth × Height
|
200 ×25 ×57.9 mm
|
|
Dry Weight
|
420 g
|
|
Number of Nozzles (In Effective Print Width)
|
2,656 (2,558)
|
|
Standard Resolution
|
600 × 600 dpi
|
|
Effective Print Width
|
108.25 mm
|
|
Max. Drive Frequency
|
30 kHz
|
|
Max. Print Speed
|
75 m/min
|
|
Drop Volume
|
5 pL, 7 pL, 12 pL, 18pL (under 20 kHz)
|
|
Optimum Ink Viscosity
|
5.0 – 6.0 mPa*s
|
|
Compatible DTG Printers
|
aeoon Compact, aeoon Compact Plus, aeoon Kyo, aeoon Kyo Plus, aeoon Hybrid
|
The Kyocera KJ4B-QA printhead is a 600dpi one-color printhead with a maximum drive frequency of 30kHz. It delivers high quality with a small drop volume of 5pl at 75 m/min by making use of 2,656 nozzles arranged across 108.25 mm wide print swathe with 0.042mm pitch, resulting in 30.000 drops per second.
One of the key advantages of the KJ4B-QA printhead is its high printing speed, with a maximum firing frequency of up to 30kHz. This allows fast and efficient printing with aeoon Compact Series, aeoon Kyo Series and aeoon Hybrid printers, making it an ideal choice for high-volume printing applications.
Configuration
The aeoon Kyo Series Printer can be configured in several different ways, depending on the number of printheads:
Kyo 4/2 and
Kyo 4/3=
4 Printheads
+
2 or 3 Tables
Kyo 8/2 and
Kyo 8/3=
8 Printheads
+
2 or 3 Tables
Kyo 12/2 and
Kyo 12/3 =
12 Printheads
+
2 or 3 Tables
The 4, 8 or 12 printheads in the aeoon Kyo Series DTG printer can be configured according to your needs.
The version with 4 printheads can print in CMYK on light and white garments.
The version with 8 printheads can either print:
- with twice the CMYK heads on light and white garments,
- or in CMYK and White on every color, including dark and black garments,
- or in extended gamut – CMYK + spot colors (Red and Green) and White on every color, including dark and black garments.
The version with different configurations of 12 printheads can print on every color of the garment, including dark and black, using either CMYK and White or CMYK + spot colors (Red and Green) and White.
*) S means Gamut Expansion Colors (GECs like red, orange or green -depending on the ink set.
Kyo PLUS
aeoon PLUS series: Pressing and printing in one GO!
The aeoon Kyo Plus takes print quality and efficiency to the next level with its Integrated Heat Press feature. By combining the printing and heat pressing processes into one seamless operation, it offers numerous advantages:
- It provides the ability to pre-press and after-press garments directly within the system, eliminating the need for an external heat press and reducing the number of work steps.
- It increases the print quality and helps with the washability of the print with the garment being pressed in-between the application of the white underbase and the color layer.
No heat press marks
No external heat presses
Streamlined workflow
with integrated
40 x 50cm heat presses
Improved washability
of the print
aeoon Kyo PLUS printer: a sneak peek at the integrated heat press inside
Differences between aeoon kyo Series printer and aeoon Kyo PLUS Series Printer
|
|
aeoon Kyo
|
aeoon Kyo Plus
|
|---|---|---|
|
Amount of printheads:
|
4, 8 or 12
|
8 or 12
|
|
Color Channels:
|
|
n/a for CMYK only
|
|
Integrated Heat Press:
|
No
|
For each printing station; Press size: 40 x 50 cm
|
|
Machine Size:
|
410 x 290 x 200cm
|
410 x 290 x 200cm
|
|
Machine Weight:
|
2000 kg
|
2450kg
|
Inks
DuPont Color G Series
The aeoon Compact Series, aeoon Kyo Series and aeoon Hybrid DTG Printers use DuPont Color G Series water-based pigment ink, designed to produce vibrant and long-lasting colors on various fabrics.
The ink is specially formulated to provide excellent adhesion to materials, ensuring that the printed designs are durable and wash-resistant. The water-based nature of the ink makes it an environmentally friendly option, as it does not contain harmful solvents or chemicals.
Expanded Color Range – Spot Colors
For DTG printers using only CMYK colors, it is not possible in some cases to recreate the vibrancy and brightness of an RGB picture in a print. That is because the colors required are simply „out of gamut“ – they are not in the CMYK color range. With gamut expansion colors (so-called “spot”) – additional process colors, such as RED and GREEN – in addition to the standard colors cyan, magenta, yellow, black and white, it is finally no longer necessary to compensate that loss or try to balance it out with tweaks!
Advantages of expanding your color space
Advantages of gamut expansions are larger color gamut and improved transitions between colors, easiness to hit pantone colors accurately (similar to screen printing color matching) and improved color brilliance, resulting in the print being closer to the original RGB design.
Sustainable high-quality water-based pigment inks
Water based ink, which is made by suspending a biodegradable pigment into a water base, has gained popularity within the DTG printing industry due to its combination of quality, affordability, and eco-friendliness. Reducing the environmental footprint is one of the biggest advantages of using water-based pigment inks.
DuPont Color G Series inks are GOTS-approved and OEKO-TEX® approved.
GOTS – Global Organic Textile Standard
GOTS is a leading international set of rules for the production and trade of natural textiles. This set of rules does not only cover ecological criteria but social criteria in the production of products as well – this includes the payment of the minimum wage, trade unions, safe working conditions and a ban on child labour.
OEKO-TEX®
OEKO-TEX® enables consumers and companies to make responsible decisions which protect our planet for future generations. The testing and certification process on which our standards are based guarantees maximum consumer safety.
RIP
aeoon RIP software
The RIP software used for aeoon DTG printers enhances the printing process by improving color accuracy, image quality, and overall efficiency. Users can control and adjust various printing parameters and benefit from using multiple features:
- Color control
- White ink handling
- Job tracing and accounting
- Ink cost calculator
- XML-based, barcode controlled workflow for job automation
- Pallet organizer
- Port and Print queue managers
The RIP software is configured based on the number of printheads in your aeoon DTG printer and is offered with a software protection USB key required for use on your system. One software license is offered per computer / printer.
Software Add-ons
To produce exceptional output quality with excellent details, multiple software add-ons can be additionally installed:
- Expanded Color Gamut (CMYK to CMYK+RG)
- Color Tools: Named Color Space, Direct Channel Firing, Direct Color Editing, Color Book
- Profiling Tool 4 Color Edition (CMYK + W)
- Profiling Tool 6 Color Edition (CMYK + RG + W)
Brochures
Technical Data
Printable textiles:
Cotton, synthetics, mixed fibers, canvas, wood, leather
Maximum print size:
Frame: with 2 or 3 print stations – 40 x 50 cm; ~ 16 x 20 in
Frameless: with 2 or 3 print stations – 60 x 90 cm; ~ 24 x 35 in
Flameless: with 1 print station – 200 x 98 cm; ~ 79 x 39 in
Printhead:
Printing resolution:
600 dpi up to 2400 dpi resolution
Supported operating systems:
Linux OS
Electrical Supply:
3 x 400/208 V + N + PE, 50/60 Hz (+/-5%)
Max. power input:
- Kyo: 8.5 kVA;
- Kyo PLUS: 8.5 kVA + 6.3 kVA
Interface:
OPC-UA and REST interface
RIP Software
aeoon RIP Software
Crash Prevention:
Integrated
Ink Types & Volume
Water based pigment ink, 10l Container for each color
Environmental conditions:
Temperature: 22 – 24°C; Humidity 50 – 80 % non – condensing
Compress Air Supply:
7 bar – Quality Class 5 (residual oil: 25mg/mÑ – residual dust: 40μm/ 10mg/mÑ – residual water +7 DTP /7.8 gm/m³)
Max. air consumption: 500L/min
Dimensions and Weight:
- Kyo Series: 410 x 290 x 200cm / ~ 161 x 114 x 79 in / 2000 kg / 4409 Ib
- Kyo Plus Series: 410 x 290 x 200cm / ~161 x 114 x 79 in / 2450kg / 5400 Ib
Featured Videos
aeoon Kyo Series printer
6 Videos
aeoon Kyo Series DTG | Sample prints
The aeoon Kyo DTG printer can produce high-quality prints at fast speeds, allowing to output large volumes of garments in a short amount of time. This is particularly useful for businesses that need to meet tight production deadlines or produce large quantities of garments on-demand.
